AT76C712-JT064

AT76C712-JT064, Microcontroller unit(MCU), QFP-64, 3.3V, 12MHz, ATMEL Corporation

Rated 5 Rating 5 | reviews | Write a review

Price:: US $3.15~3.55 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $3.15~3.55

PartNumber:: AT76C712-JT064

Brand:: ATMEL Corporation - ATMEL | Pack: QFP | D/C: 05+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Kevin's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-06-05

From Other Seller

Part Number:AT76C712-JT064
US $3.15 - 3.55
EKXG401ELL6R8MJ16S

US $5.00 - 5.00 / Piece
(0) Remove
EKZE250ELL152MK25S

US $0.10 - 1.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The AT76C712-JT064 is a Microcontroller unit(MCU). The device is based on the AVR-enhanced RISC architecture core, which combines an advanced instruction set with 32 general-purpose working registers. By executing powerful instructions in a single clock cycle, the AT76C712-JT064 achieves throughputs approaching 1MIPS per MHz, allowing the system designer to optimize power consumption versus processing speed.

Parametrics

AT76C712-JT064 absolute maximum ratings: (1)Voltage rating: 3.3V; (2)12 to 48MHz.

Features

AT76C712-JT064 features: (1)Advanced RISC Architecture, 130 Powerful Instructions, Most Single Clock Cycle Execution; (2)JTAG (IEEE Std. 1149.1 Compliant) Interface; (3)Clock Generator Provides CPU Rates up to 48MHz; (4)Only One External Clock Crystal of 12 MHz Can Generate All the Required System Clocks.; (5)Two On-chip 16550 UARTs Supporting Baud Rates up to 921 Kbaud; (6)On-chip Bootstrap ROM Provides a Variety of Firmware Upgrade Modes; (7)DMA Channels Allow Fast Data Transfers between Endpoint Buffers and Internal or External SRAM (DMA Transfer Rate is 12 MHz for All Channels); (8)8K x 16 bits (up to 11K x 16 bits), In-System SRAM for Program Code (Program Memory); (9)On-Chip 8 Kbytes SRAM for Data and Variables ( 2, 4, and 8 Kbytes can be Remapped for Program Storage in the Address Area Above the Program Memory); (10)Two 8-bit Timer/Counters; (11)One 16-bit Timer/Counter; (12)Two External interrupts Through GPIOs; (13)Programmable Watchdog Timer; (14)Low voltage operation; (15)Low cost 64-pin TQFP Package, Suitable for USB-to-UART Bridge Applications.
