Product Summary

The SD1488 is a 12.5 V Class C epitaxial silicon NPN planar transistor designed primarily for broadband applications in the 450 - 512 MHz land mobile radio band. This device utilizes diffused emitter resistors to withstand infinite VSWR at rated operating conditions.

Parametrics

SD1488 absolute maximum ratings: (1)VCBO, Collector-Base Voltage: 36 V; (2)VCEO, Collector-Emitter Voltage: 16 V; (3)VEBO, Emitter-Base Voltage: 4.0 V; (4)IC, Device Current: 8.0 A; (5)PDISS, Power Dissipation: 117 W; (6)TJ, Junction Temperature: +200鈩? (7)TSTG, Storage Temperature: -65 to +150鈩?

Features

SD1488 features: (1)470 MHz; (2)12.5 Volts; (3)efficiency 50%; (4)common emitter; (5)Pout = 38 W min. with 5.8 dB gain.

Diagrams

<IMG border=0 alt="SD1488 pin connection" src="http://www.seekic.com/uploadfile/ic-mfg/201271831444473.jpg">

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
SD1488
SD1488
STMicroelectronics
Transistors RF Bipolar Power NPN 12.5V 470MHz
Data Sheet
Negotiable
