Product Summary

The PAC1284-04Q is a p/active ieee 1284 ecp/epp termination network. It is used to provide communications with external devices such as tape back-up drives, ZIP drives, printers, parallel port SCSI adapters, external LAN adapters, scanners, video capture, and other PC peripherals. The applications of the PAC1284-04Q include: ECP/EPP Parallel Port termination, EMI/RFI filter, Notebook and Desktop computers, Engineering Workstations and Servers.

Parametrics

PAC1284-04Q specifications: (1)Absolute Tolerance (R): ±10%; (2)Absolute Tolerance (C): ±20%; (3)Operating Temperature Range: 0℃ to 70℃; (4)VCC: 6V max; (5)Power Rating/Resistor: 100mW; (6)Maximum Leakage Current(at VCC Max): 1μA@25℃; (7)Storage Temperature: -65℃ to 150℃; (8)Package Power Rating: 1.00W, max.

Features

PAC1284-04Q features: (1)Stable resistor-capacitor network; (2)9 terminating lines/package; (3)Saves board space, reduces assembly cost, simplifies routing; (4)ESD protected; (5)Miniature QSOP package.

Diagrams

PAC1284-04Q diagram
