The SNJ54LS244J octal buffer and line driver is designed specifically to improve both the performance and density of three-state memory address drivers, clock drivers, and bus-oriented receivers and transmitters.
Parametrics
SNJ54LS244J absolute maximum ratings: (1)Supply voltage, VCC: 7 V; (2)Input voltage, VI: LS: 7 V, S: 5.5 V; (3)Off-state output voltage: 5.5 V; (4)Package thermal impedance, θJA: DB package: 70℃/W, DW package: 58℃/W, N package: 69℃/W, NS package: 60℃/W; (5)Storage temperature range, Tstg: –65℃ to 150℃.
Features
SNJ54LS244J features: (1)3-State Outputs Drive Bus Lines or Buffer Memory Address Registers; (2)PNP Inputs Reduce DC Loading; (3)Hysteresis at Inputs Improves Noise Margins.
