AT25F1024AN-10SU-2.7

SPI Serial Flash Memory, 1MBIT, 33MHZ, 8SOIC, 2.7 V ~ 3.6 V

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.56~0.72 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.56~0.72

PartNumber:: AT25F1024AN-10SU-2.7

Brand:: ATMEL Corporation - ATMEL | Pack: DIP | D/C: 07+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Kevin's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-03-23

From Other Seller

Part Number:AT25F1024AN-10SU-2.7
US $0.56 - 0.72
EKY-160ELL121MF11D

US $0.10 - 1.00 / Piece
(0) Remove
LM64P101

US $240.00 - 300.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The AT25F1024AN-10SU-2.7 is a 1Mbit High Speed SPI Serial Flash Memory. It provides 1,048,576 bits of serial reprogrammable Flash memory organized as 131,072 words of 8 bits each. The AT25F1024AN-10SU-2.7 is optimized for use in many industrial and commercial applications where low-power and low-voltage operation are essential. The AT25F1024AN-10SU-2.7 is available in a space-saving 8-lead JEDEC SOIC and 8-lead SAP packages.

Parametrics

AT25F1024AN-10SU-2.7 absolute maximum ratings: (1)Operating Temperature:–40℃ to +85℃; (2)Storage Temperature:–65℃ to +150℃; (3)Voltage on Any Pin with Respect to Ground:–1.0V to +5.0V; (4)Maximum Operating Voltage:4.2V; (5)DC Output Current:5.0 mA.

Features

AT25F1024AN-10SU-2.7 features: (1)Serial Peripheral Interface (SPI) Compatible; (2)Supports SPI Modes 0 (0,0) and 3 (1,1): Datasheet Describes Mode 0 Operation; (3)33 MHz Clock Rate; (4)Byte Mode and 256-byte Page Mode for Program Operations; (5)Sector Architecture: Four Sectors with 32K Bytes Each (1M), 128 Pages per Sector; (6)Product Identification Mode; (7)Low-voltage Operation:2.7 (VCC = 2.7V to 3.6V); (8)Sector Write Protection; (9)Write Protect (WP) Pin and Write Disable Instructions for both Hardware and Software Data Protection; (10)Self-timed Program Cycle (20 μs/Byte Typical); (11)Self-timed Sector Erase Cycle (1 second/Sector Typical); (12)Single Cycle Reprogramming (Erase and Program) for Status Register; (13)High Reliability: Endurance: 10,000 Write Cycles Typical, Data Retention: 20 Years; (14)Lead-free/Halogen-free Devices; (15)8-lead JEDEC SOIC and 8-lead SAP Packages.
